Description
Hand Cutter model HC35 –
The ultrasonic hand cutting unit HC35 is suitable for manual cutting and sealing applications. With an operating frequency of 35 kHz the HC35 is suitable for manual cutting of synthetic textiles. The hand cutter can be operated with an Ecoline generator, an RDG generator, or an SDG generator.
Generator comparison data with the HC35 Hand Cutter:
| HC35 | Ecoline generator | RDG generator | SDG generator |
| Power | 400 W | 750 W / 400 W | 750 W / 400 W |
| Time mode |  | ||
| Energy mode | | ||
| Time and /or energy mode | | ||
| Contact breaker | | | |
| Continuous welding | | | |
| Variable amplitude | | | |
| (40% – 100%, in increments of 10%) | (40% – 100%, in increments of 10%) | (15% – 100%, in increments of 1%) | |
| TEST key | | | |
| Status LED on generator | Ultrasonic ready / active / error | Ultrasonic ready / active / error | Ultrasonic ready / active / error |
| LCD | | ||
| Carrying case | | ||
| Handle on generator | | ||
| Dimensions (WxHxD) | 191 mm x 102 mm x 282 mm | 150 mm x 285 mm x 430 mm | 150 mm x 285 mm x 430 mm |
Documents
Brochure Rinco HC35 Ultrasonic Hand Cutter
Brochure Eco Line Generator for Hand Units
Brochure Cutting & Welding Textiles
