SDG Generator
Standard digital generator with process settings for production stations.
The SDG adds production process control to Rinco's digital generator platform: weld-relevant settings, monitoring and I/O for stations and machines, with automatic frequency tracking and consistent amplitude regulation at its core.
- Operating frequency
- 20 kHz
- Weight
- 1.8 kg including transducer
- Amplitude through integrated transducer (amplified 1
- 1.5)
- Suitable Generator types
- RDG20-1000, SDG20-1000
Defining features
- Interactively programmable
- Multirack for similtanious operation of several modules - optional
- Softstart function
- Softstop function
- Made in Switzerland
Technical specifications
| Operating frequency | 20 kHz |
|---|---|
| Weight | 1.8 kg including transducer |
| Amplitude through integrated transducer (amplified 1 | 1.5) |
| Suitable Generator types | RDG20-1000, SDG20-1000 |
