35 kHz01 / 01Click to expand ⤢Hand-held ultrasonic welder · Ultrasonic Hand Units
HT 35 Hand Welder
35 kHz hand unit configured for tacking and fixing work.
The HT 35 configures Rinco's 35 kHz hand-welding platform for tacking and fixing: quick, controlled energy for holding parts in position, fixing textiles and pre-assembly work ahead of final welding.
- Operating frequency
- 35 kHz
- Switches
- On the hand grip with adjustable activation point
- Weight
- 1.2 kg including transducer
- Amplitude amplification
- Integrated transducer (amplified 1:1.5)
- Generator suitability
- Eco Line35-400, RDG35-400/750, SDG35-400/750
Defining features
- Automatic triggering by activating the integrated microswitch
- Integrated transducer with rotary protection against cable damaging
- Rugged construction for optimal sound propagation
- Small and light weight
- Made in Switzerland
Technical specifications
| Operating frequency | 35 kHz |
|---|---|
| Switches | On the hand grip with adjustable activation point |
| Weight | 1.2 kg including transducer |
| Amplitude amplification | Integrated transducer (amplified 1:1.5) |
| Generator suitability | Eco Line35-400, RDG35-400/750, SDG35-400/750 |
