HG 20 Hand Welder
High-power 20 kHz hand welder for spot welding and staking larger parts.
The HG 20 delivers 20 kHz power in a hand-held package for spot welding, staking and tacking of larger thermoplastic parts. A flexible workhorse for rework, low-volume assembly and jobs a bench press can't reach.
- Operating frequency
- 20 kHz
- Weight
- 1.8 kg including transducer
- Amplitude amplification
- Through integrated transducer (amplified 1:1.5)
- Generator suitability
- RDG20-1000, SDG20-1000
Defining features
- Rugged construction for optimal sound propagation
- Very high performance
- Protected cable duct
- Made in Switzerland
Technical specifications
| Operating frequency | 20 kHz |
|---|---|
| Weight | 1.8 kg including transducer |
| Amplitude amplification | Through integrated transducer (amplified 1:1.5) |
| Generator suitability | RDG20-1000, SDG20-1000 |
